The many different tap installations used in healthcare facilities presents a challenge to installing a suitable and compatible point of use water filter.
Tap outlets vary significantly in terms of their configuration, outlet connection diameter, mode of operation, and installation distance from the wash basin.
This might have a significant impact on the safe operation of a water filter.
Compatibility Challenge
The implications of installing a non-compatible tap filter can be significant, the consequences of which may be detrimental to end user safety, infection prevention, and control practices and create a compliance breach.
Where the installation of a filter impacts the area between the outlet and basin, reducing the available space for effective hand hygiene practices, often a challenge with shallow basins.
Where the installation of the filter breaches the air gap, contravening local regulations e.g. TWIN12 in Germany.
Where the filter may impede the intended operation of the tap, such as impacting vertical or horizontal levers and obscuring IR sensors.
Where water may flow directly into vertical drains causing splashback.
Where the aforementioned compatibility issues contribute either in isolation or in tandem to increasing the risk of retrograde contamination of the filter, through handling during use or back splashing from contaminated reservoirs such as drains.
‘’Right Filter for the Right Outlet’’
A ‘one size fits all’ approach to installing filters for the wide range of tap and basin configurations used in healthcare is therefore not a practical solution.
Choosing the ‘right filter for the right tap outlet’ is an important consideration in product selection, as compatibility can have a significant impact on a filter, the outlet, and how end users interact with it. Ultimately, compatibility is a critical factor in maintaining the efficacy of control in waterborne pathogen infection prevention where filters are deployed.
At T-safe we recognise and understand the challenges, complexities, risks, and nuances involved. Our goal is not only on ‘delivering safe water’ but also on ensuring that our filtration solutions optimise outlet usability and end-user comfort. To that end, we offer a range of Medical Tap Filter solutions that provide greater choice and flexibility in product selection.
Medical Tap Filter Side Mount
An ideal solution for shallow wash basins with limited activity space, non-touch sensor taps, and vertical siphon wash basins.
Medical Tap Filter Fixed Position
Ideal solution for wall mounted taps and swan neck taps, where the filter acts as an extension of the outlet.
Top Tips for Filter Selection
- Ensure that on the installation of a filter a sufficient Activity Space is maintained, to enable effective hand washing by end users.
- Ensure that the operation of Sensors on non-touch taps is not impeded by the installation of a filter.
- An Air Gap, of minimum 20mm from the top of the basin to the filter outlet must be maintained, to prevent back siphon of water upstream.
- The filter should not impede the full extension of Tap Levers, nor should tap levers come into contact with the filter.
- The Wash Basin Configuration should be considered, ensuring that the water outlet does not flow directly into vertical siphons.
